0010-F3
Taco 0010-F3 1/8HP Cast Iron Cartridge Circulator Pump
Taco High Velocity Series 0010-F3 is a 1/8 horsepower Cartridge Circulator designed for quiet, efficient operation in a wide range of residential and light commercial, medium-head/medium-flow water circulating applications. Available in cast iron or bronze construction. Bronze is designed for all open-loop fresh water systems. Unique, replaceable cartridge contains all of the moving parts so you can service it easily instead of replacing the entire unit. Compact, direct-drive, low-power consumption design is ideal for high efficiency jobs.
Features
Standard High Capacity Output Compact Design
Quiet, Efficient Operation
Unique Replaceable Cartridge Design-Field Serviceable
Direct Drive-Low Power Consumption
Self-Lubricating
No Mechanical Seal
Unmatched Reliability --Maintenance Free
Universal Flange-to-Flange Dimensions
Cast Iron or Bronze Construction
Typical Applications
Hydronic Heating
Radiant Heating
Primary-Secondary Loops
Indirect Water Heaters
Chilled Water Cooling
Potable Hot Water Systems
Performance Data
Flow Range: 0-30 GPM
Head Range: 0-11.5 Feet
Minimum Fluid Temperature: 40 degrees F (4 degrees C)
Maximum Fluid Temperature: 230 degrees F (110 degrees C)
Maximum Working Pressure: 125 PSI
Connection Sizes: 3/4", 1", 1-1/4", 1-1/2" Flanged
