Genesis 24/2 BACnet Blue Twisted Pair Communication Wire, 1000ft
Specs not yet added for this product. See the Description tab for full details.
Please refer to the product description or manufacturer documentation for included items.
Plenum Rated EIA-485 Communication Cable
Part Number: 33192106 1000' Reel-in-a-Box / Blue
24 AWG 1 Stranded Pair Shielded Low-Cap
Ratings CMP, CL3P, FPLP, FT6
Approvals UL Listed
Construction
Conductor 24 AWG 7 Strand Bare Copper
Conductor Count 2 (1-pair)
Insulation FEP (0.024" nom.)
Insulation Colors Black, White
Lay Length 2" nom.
Shielding Aluminum Foil/Mylar w/ 24 AWG Tinned-Copper Drain
Rip Cord Yes
Jacket Plenum PVC (0.015 " nom.)
Overall Diameter 0.164" nom.
Print Legend GENESIS LOW CAP EIA/TIA-485 P/N 3319 1PR 24AWG SHIELDED E175106 (UL) CL3P OR
FPLP OR CMP C(UL)US FT6 75C (RoHS) W/O# XXXXXX-XXXXXXX XXXXFT A B C D E
F 1 2 3 4 5 6 7 8 9
Properties
Operating Voltage 300 Volts max.
DC Resistance 26.7 Ohms/1000' at 20°C
Capacitance 12.5 pF/ft. nom.
Impedance 115 Ohms nom.
Temperature -20°C to 75°C
Flame Rating NFPA 262 (Plenum); CSA C22.2 No. 2556 (FT6)
RoHS Compliant Yes
Country of Origin USA
