Johnson Controls M9108-AGC-2 Non-Spring Return Electric Actuator
Specs not yet added for this product. See the Description tab for full details.
Please refer to the product description or manufacturer documentation for included items.
The Johnson Controls M9108-AGC-2 Electric Actuator, Non-Spring Return, Shaft Type Self-Centering Clamping
Features:
Simple direct coupling reduces installation and commissioning time while improving reliability by eliminating damper linkages
Robust 70 lb-in (8 Nm) torque rating
Rotation range 0 to 90° in 5° increments, mechanically limited to 93°
Fits 3/8 to 3/4 (10 to 20 mm) round shaft, 3/8 to 5/8 (10 to 16 mm) square shaft; 1 (25.4 mm) diameter jackshaft with M9000-154 adapter
On-off, floating and proportional control inputs meet the needs of most applications
Output position feedback provides simple closed-loop control with accurate position sensing
Electronic stall detection ensures higher reliability by deactivating the actuator motor when a stall condition is detected
Jumper selectable DC 0(2).10 V or DC 0(4).20 mA, proportional control
Zero and span adjustment (HGx models)allows sequential operation of dampers from a single input signal of DC 0(2).10 V, DC 0(4).20 V or DC 0(4).20 mA
Jumper-selectable rotation direction and manual gear release simplify installation, setup, and field adjustments
2-SPDT optional auxiliary switches
1/2 NPT threaded housing provides easy connection for electrical fittings
Manual gear release simplifies damper / valve setup and commissioning
-4 to 122°F (-20 to 50°C) ambient temperature range
Rated for 60,000 full stroke cycles
UL Listed, CSA Certified, CE Mark
