Mars 10584 1/4HP Direct-Drive Furnace Blower Motor, 208-230V
Specs not yet added for this product. See the Description tab for full details.
Please refer to the product description or manufacturer documentation for included items.
MARS 10584 is 1/4 horsepower, 208-230 volt direct drive furnace blower motor with three speeds standard efficiency models. MARs direct drive blower motors are electrically reversible and include 2-1/4 inch resilient rings for base mounting and all angle sleeve bearings and have open air over enclosures.
Features
Sleeve bearing
Rheem mounting holes
3 speeds
1/2 inch extended thru bolts
2-1/4 inch resilient rings
For accessories see pages
M-44 – M-46
Specifications
Motor Type: PSC
Enclosure: OAO
H.P. (Max.): 1/4
Voltage: 208-230
Speeds: 3
Hz: 60
Rotation: Reverse
RPM Range: 1075
NEMA Frame Size: 48
Phase: Single
Standards: CUL
FLA: 1.8
Mount: All Angle
Bearing: Sleeve
Shaft Length Inches: 4.5
Shaft Dia Inches: 1/2
Thermal Protection: Auto
Ambient Deg C: 40
Insulation Class: Class B
Capacitor Included: No
Capacitor Rating: 5/370
Fan duty, continuous,air over
36 inch leads
UL Recognized
